SATA AE5202 4.5T 4 POST LIFT FOR ALIGNER

SATA AE5202 4.5T 4 POST LIFT FOR ALIGNER

Serial No

AE5202

Description

  • Capacity : 4.5T
  • Min. Lift Height : 210mm
  • Max. Lift Height : 1700mm
  • Rise Time : 60S
  • Drop Time : 50S
  • Motor Power : 2.2KW
  • Motor Shell : Aluminum Alloy
  • Machine Height : 2108mm
  • Width between column : 2830mm
  • Track Width : 3185mm
  • Platform Length : 4510mm
  • Electric Control : 24V Control Box
  • Unlock Detection : Yes
  • Lock Release : Pneumatic
  • Machine weight is 1300KG
  • The whole machine passed 1.5 times load test
  • The platform adopts steel plate bending technology, increase the strength
  • The reinforcing bar at the bottom of the platform is designed with U-shaped steel to increase the strength
  • Electronic detection of the state of insurance, to avoid falling in the process of insurance not fully open caused by potential safety hazards
  • Wire rope fracture protection, avoid wire rope fracture caused safety hazard
  • Aluminum alloy motor, fast heat dissipation
  • ★ Pneumatic lock release with single side, more safe operation
  • ★ 24V safety voltage control, more safe operation
  • ★ 4510mm extended platform, suitable for more vehicle model
